Kubota GeneratorsJ320
Kubota GeneratorsJ106
Prime Output 5.5 kVA (5.5 kW)
Standby Output 6.0 kVA (6.0 kW
Description
Prime Output 20.0 kVA (16.0 kW)
Standby Output 22.0 kVA (17.6 kW)
Additional information
| Type | Revolving field, AC generator |
|---|---|
| Frequency | 60 Hz |
| Standby Output | 13.7 (11.0)kVA (kW)a |
| Prime Output | 12.5 (10.0)kVA (kW) |
| Phase / Wire | 3/4 |
| Power Factor | 0.8 |
| No. of Poles | 2 |
| Insulation | Rotor coil; class F, Stator coil; class B |
| Type of Coupling | Direct coupled |
| Single Phase 110V | N/A |
| Single Phase 127V | 19.7 x 3 |
| Single Phase 220V | N/A |
| Single Phase 240V | N/A |
| Three Phase 220V | 32.8 |
| Three Phase 380V | N/A |
| Three Phase 415V | N/A |
| Terminal | Available |
| DIESEL ENGINE Type | Vertical, water-cooled, 4-cycle diesel engine |
| DIESEL ENGINE Model | D722 |
| No. of Cylinders | 3 |
| Bore x Stroke | 67.0 x 68.0 mm |
| Displacement | 0.719 L |
| Engine Speed | 3600 |
| Continuous Rated Output | 12.3 (16.5) |
| Lubricant (API classification) | above CD grade |
| Oil Capacity | 3.4 L |
| Coolant Capacity | 3.0 L |
| Starting System | Electric – 12 volt DC |
| Fuel | Diesel fuel No.2 (ASTM D975) |
